AGM NVG-40" is a two-channel night vision device. With a 40° viewing angle, it provides a large viewing area without necessarily moving the binoculars. NVG-40 uses state-of-the-art multi-coated lenses and is designed in a space-saving compact design. Running on a single alkaline AA or CR123A power pack, the NVG can last up to 20 hours. It also has a built-in infrared illuminator for dark sensing.
For use as a hands-free NVG, it can be fitted to many types of brackets such as AN/PVS-7D, AN/PVS-14, AN/PVS-7A/C, AN/PVS-15, and AN/PVS-18, or to mini-rail interface arms.
Image Intensifier Tube
Gen 2+ "Level 1"
Field of view cleanness by zone
Gen 2 IIT NL1 is the highest resolution and the cleanest offered by AGM. There are practically no visible spots in Zone 1.
27 mm, F/1.3
0.25 m to Infinity
-6 to +2 dpt
Low Battery IR On Excessive Light Conditions
Yes; Two power levels
Manual Gain Control
Bright Light Cut-Off
Automatic Shut-Off System
One CR123A (3V) or AA (1.5 V)
Battery Life (Operating)
Up to 20 hours at 20°C (up to 80 hrs with optional battery pack)
Operating Temperature Range
-40°C to +50°C (-40°F to +122°F)
Storage Temperature Range
-50°C to +70°C (-58°F to +158°F)
645 g (1.42 lbs)
115 × 118 × 74 mm (4.5 × 4.6 × 2.9 in)
Night Vision Goggles, Goggle Kit, Soft Carrying Case, Lens Cloth, Battery Adapter, User Manual
