AGM ASP TM25-384

Thermal imaging
Part #3093451006AS21
0 reviews | Write a review
Thermal imaging
Part #3093451006AS21
0 reviews | Write a review

Characteristics
  • Detector type: Vanadium Oxide Uncooled Focal Plane Arrays
  • Refresh rate: 50 Hz
  • Resolution: 384 × 288
  • FOV: 14.88° x 11.19°
Export Restrictions:
Item demonstrated in this is dependent upon US trade guidelines and may require a permit preceding fare. Any redirection in opposition to US Government guidelines is denied.
Compare
Package Includes
  • Operators Manual
  • Protective Bag
  • Neck Lanyard
  • Lens Tissue
  • USB Cable
$1,884.00
Quick Order
Add to cart

Description And features

The Asp TM-384 Portable Thermal Monocular for observation is fitted with an IR sensor 384 × 288 and an OLED monitor 1024 × 768. It provides the following features: monitoring, tracking of hot spots, distance measurement, Wi-Fi, ets. The newly developed high sensitivity integrated heat sensor ensures clear images even in complete dark conditions. The monocular is mostly applied to situations like police patrols, law and order, search and rescue, narcotics control, contraband, illegal capture, trekking, trail and hunting, etc. FUNCTIONS Distance meter: The gadget provides a distance measurement feature after mark-up the top and bottom of the goal and input the target height. Hot Spot Mark: The gadget identifies and notes the highest temp-point of a hot spot. Wi-Fi & Hot Spot: The product can take shots, capture video and setup options through APP after being connected to the smartphone. Switching modes: The unit includes a pallet switch and distance reading. Storage: The integrated storage module can record video/photo. Digital zoom: The device provides 1× and 2× digital zoom capability.

  • Up to five hours continuous running (with Wi-Fi hot spot function off)
  • 384 × 288 resolution, high sensitivity detector
  • Wi-Fi hot spot/ Limited 3-Year Warranty
  • 1024 × 768 resolution 0.39-inch OLED display
  • Built-in rechargeable Li-ion battery
  • Adaptive AGC, DDE, 3D DNR, NETD less than 35 mk (@25°C), F#=1.0


Specifications

Image sensor

Vanadium Oxide Uncooled Focal Plane Arrays

Max. Resolution

384*288

Detector Pitch

17um

Response Wavebond

8um to 14um

NETD

< 35mk(@25°C,F#=1.0)

Optical magnification

1.7x

Lens (focal length)

25mm

Field of view (H × X)

14.88° x 11.19°

F number

1.0

Digital zoom

2X

Monitor

0.39-inch, OLED, 1024 × 768

Hot Track

Yes

Imaging palettes

Black hot White hot Red hot Fusion

Storage

Built-in memory module (16GB)

Record Video

Support on-board video recording

Capture Snapshot

Yes

Battery Type

Lithium Battery

Wi-Fi

Yes

Battery Operating Time

Up to 5 hours continuous running

Battery Capacity Display

Yes

Power supply

5V DC/2A, 2W

Weight

460 g (1.01 lb)

Working Temperature/ Humidity

-30 °C to 55 °C (-22 °F to 131 °F)

Overall Dimensions

189 mm × 74 mm × 66 mm (7.9″ × 2.91″ × 2.60″)

Protection Level

IP67
